| Axial pitch | Display after one revolution | Max speed(r/m) | ||
|---|---|---|---|---|
| 1.0mm | Norm 0001,0≡ | Or 000,10≡ | Or 00010≡ | 1500 |
| 1.5mm | Norm 0001,5≡ | Or 000,15≡ | Or 00015≡ | 1000 |
| 1.75mm | Norm 0001,7/5 | Or 000,17/5 | Or 00017/5 | 850 |
| 2.0mm | Norm 0002,0≡ | Or 000,20≡ | Or 00020≡ | 750 |
| 2.5mm | Norm 0002,5≡ | Or 000,25≡ | Or 00025≡ | 600 |
| 3.0mm | Norm 0003,0≡ | Or 000,30≡ | Or 00030≡ | 500 |
| 4.0mm | Norm 0004,0≡ | Or 000,40≡ | Or 00040≡ | 450 |
| 5.0mm | Norm 0005,0≡ | Or 000,50≡ | Or 00050≡ | 300 |
| 6.0mm | Norm 0006,0≡ | Or 000,60≡ | Or 00060≡ | 300 |
| 8.0mm | Norm 0008,0≡ | Or 000,80≡ | Or 00080≡ | 250 |
| 10.0mm | Norm 0010,0≡ | Or 001,00≡ | Or 00100≡ | 150 |
